CONTAINER CHIPPER
Wüst SMC-812 CCL
The SMC-812 CCL is a container-style configuration in the Wüst Hacker SMC-812 family. It keeps the focus on professional wood chipping performance while giving operators a modular setup for transport, placement and site workflows.
Get information
MACHINE DETAILS
Key information
- SMC-812 chipping unit in container configuration
- Designed for trunk wood, branches and crown material
- Cutting length concept from 15 mm to 45 mm
- Service-friendly access around knife, rotor and sieve areas
PRODUCT OVERVIEW
How it fits the operation
SMC-812 CCL is part of the Wüst Hacker SMC-812 machine family for professional wood chipping. The family is built around a high-capacity chipping unit and is configured differently depending on feeding, transport, container and drive requirements.
In a forestry or biomass workflow, the SMC-812 range is selected when chip quality, material feed, maintenance access and site logistics all matter. Smartline can compare TCR, CCL, CCR and PTO concepts according to the carrier, job type and output expectation.
APPLICATIONS
Applications
- Trunk wood, branches, crown material and residual forestry material.
- Forestry contractors and biomass supply operations.
- Field or site-based wood chipping depending on configuration.
- Operations that need consistent chip quality with professional throughput.
TECHNOLOGY
Technology
- SMC-812 chipping unit with large infeed concept.
- Cutting length concept from 15 mm to 45 mm depending on setup.
- Chainless drive and service-friendly rotor, knife and sieve access on key configurations.
- Configuration choices include crane-fed, container-based and PTO-driven workflows.
OPERATIONAL FIT
Operational fit
- Best when Wüst chip quality and machine configuration flexibility are both important.
- TCR is suitable for crane-fed mobile workflows; PTO suits powerful tractor-based operation.
- CCL and CCR support container-style logistics and positioning needs.
- Smartline can help choose configuration before price, delivery and technical matching discussions.
TECHNICAL SPECIFICATIONS
Wüst SMC-812 CCL
Core machine and system details for evaluating the right Smartline configuration for the operation.
Technical data
- SMC-812 container/crane-cabin configuration built around the same high-output chipping unit.
- Infeed size 120 x 80 cm; rotor diameter 950 mm; 6 knives of 200 mm.
- Cutting length adjustable 15-45 mm and chip size adjustable G10-G50.
- Max hardwood 60 cm, max softwood 80 cm; throughput class up to 280 m3/h depending on configuration and material.
- Low-maintenance cutter and screen base concept supports quick replacement.
CATALOG & SOURCE
Catalog and product information
Use these documents and product pages when a deeper technical review is needed.
GALLERY
Product photos
